RIGOL
© Copyright RIGOL Technologies, Inc. 2007. V
User’s Guide for DS1000 Series
General-Purpose Oscilloscopes
RIGOL DS1000-Series Digital Oscilloscopes offer exceptional waveform viewing
and measurements in a compact, lightweight package. The DS1000 series are ideal
for production test, field service, research and design and all of the applications
involving analog/digital circuits test and troubleshooting, as well as education and
training.
Each of these oscilloscopes gives you:
z Dual Channel, Bandwidth:
100MHz (DS1102CD, DS1102C, DS1102MD, DS1102M)
60MHz (DS1062CD, DS1062C, DS1062MD, DS1062M)
40MHz (DS1042CD, DS1042C, DS1042MD, DS1042M)
25MHz (DS1022CD, DS1022C, DS1022MD, DS1022M)
z Optional 16 digital channels (Mixed signal oscilloscope), each channel can be
turned on or off independently, or in a 8 bit group
z Mono/Color TFT LCD Displays at 320*234 resolution
z USB storage and printing supports, firmware upgradeable via USB connectivity
z Adjustable waveform intensity, more effective waveform viewing
z One-touch automatic setup for ease of use (AUTO)
z Saves 10 Waveforms, 10 setups, supports CSV and bitmap format
z Newly designed Delayed Scan Function, easy to give attention to both details
and overview of a waveform
z 20 Automatic measurements
z Automatic cursor tracking measurements
z Waveform recorder, record and replay dynamic waveforms
z User selectable fast offset calibration
z Built-in FFT function, Frequency Counter
z Digital filters, includes LPF, HPF, BPF, BRF
z Pass/Fail Function, optically isolated Pass/Fail output
z Add, Subtract and Multiply Mathematic Functions
z Advanced trigger types include: Edge, Video, Pulse width, Slope, Alternative,
Pattern and Duration (Mixed signal oscilloscope)
z Adjustable trigger sensitivity
