User’s Guide for DS1000 Series
the trigger level is out of the signal range. If yes, you should set the trigger level in
proper range by turning the
knob or pressing the 50% button. You could
also set the Trigger Mode as “AUTO”. Moreover, you could push AUTO button to
display the waveform on screen.
6. After the Acquisition is set to “Averages” or Display Persistence is set
ON, the waveform refreshes slowly.
It is normal in these settings.
7. The signal is displayed as ladder like waveform.
(1) The time base maybe is too slow. You can turn the horizontal
knob
to increase horizontal resolution to improve the display.
(2)Maybe the display Type is set to “Vectors”. You could set it to “Dots” mode to
improve the display.
