RIGOL
© Copyright RIGOL Technologies, Inc. 2007. 6-5
User’s Guide for DS1000 Series
Measurements
Manual Voltage difference between cursors (∆V)
Time difference between cursors (∆T)
Reciprocal of ∆T in Hertz (1/∆T)
Track Voltage value for Y-axis waveform
Time value for Y-axis waveform
Cursor
Auto Cursors are visible for Automatic Measurement
Auto Measure Vpp, Vamp, Vmax, Vmin, Vtop, Vbase, Vavg, Vrms,
Overshoot, Preshoot, Freq, Period, Rise Time, Fall Time,
+Width, -Width, +Duty, -Duty, Delay1→2
, Delay1→2
General Specifications
Display
Display Type 5.7 in. (145 mm) diagonal TFT Liquid Crystal
Display
Display Resolution 320 horizontal ×RGB×234 vertical pixels
Display Color 64K color (DS1000C, DS1000CD)
Mono (DS1000M, DS1000MD)
Display Contrast (typical) 150:1
Backlight Brightness(typical) 300 nit
Probe Compensator Output
Output Voltage(typical) 3 Vp-p into ≥1 MΩ load
Frequency(typical) 1KHz
Power
Supply Voltage 100 ~ 240 VAC
RMS
, 45-440Hz, CAT II
Power Consumption Less than 50VA
Fuse 2A, T rating, 250 V
