User’s Guide for DS1000 Series
2. The horizontal
knob moves displayed signal horizontally
on waveform window
Horizontal offset back to 0 shortcut key
Press the
knob to set the horizontal offset to 0 as a shortcut
key, this is especially helpful when the trigger point is far out of the screen and
want it to get back to the screen center immediately.
3. Press the MENU key to display the TIME menu.
In this menu, you can enter or exit the Delayed Scan mode, set the display to Y-T, X-Y
or ROLL mode, and turn the horizontal
knob to adjust trigger offset.
Horizontal position control
Trig-Offset: In this setting, the trigger position will be changed horizontally
when you turn the
knob.
