User’s Guide for DS1000 Series
Key Points:
H (High): Logic high: voltage is higher than threshold setting.
L (Low): Logic low: voltage is lower than threshold setting.
X (Ignore): Don’t care. If all the channels are ignored, the oscilloscope won’t be
triggered.
Qualifier: A timer begins when code terms are satisfied. Duration trigger occurred
in the time set by the qualifier.
