RIGOL Chapter 13 System Function Setting
13-4 DS4000E User’s Guide
Static IP: users can define the network parameters (such as the IP address,
subnet mask, gateway address and DNS server address) of the oscilloscope.
The priority of the parameter configuration from high to low is “DHCP”, “Auto IP” and
“Static IP”. The three IP configuration types can not be all turned off at the same
time.
Press Utility IO Setting LAN Set to open the network setting interface. In
the menu,
1. Select the desired IP configuration type
The priority of the parameter configuration from high to low is “DHCP”, “Auto IP”
and “Static IP”.
To use DHCP, turn on this configuration type.
To use Auto IP, turn on this configuration type and turn off the DHCP
configuration type.
To use Static IP, turn on this configuration mode and turn off the DHCP
and Auto IP configuration types.
Press Config Mode and turn the multi-function knob to select the desired
IP configuration type; press the knob or press Config Mode to turn on or off
the configuration type. When it is turned on,
is dipslayed at the front of the
configuration type name; otherwise,
is displayed.
Note: The three IP configuration types cannot be all turned off at the same
time.
Tips
When DHCP configuration type is valid, you do not need to set any
network parameter manually.
When Auto IP configuration type is valid, please set the gateway address
and DNS server address by referring to the steps below.
When Static IP configuration type is valid, please set the network
parameters (such as the IP address, subnet mask, gateway address and
DNS server address) by referring to the steps below.
2. Set the gateway address (when Auto IP or Static IP configuration
type is valid)
The format of the gateway address is nnn.nnn.nnn.nnn; wherein, the range of
the first nnn is from 1 to 223 (except 127) and the ranges of the other three nnn
