RIGOL
DS6000 User’s Guide
3. Select X (Y) Axis Unit
When the cursor type is “Time”, press Time Unit to select “s”, “Hz”, “°” or “%”.
S: when this unit is selected, in the measurement results, the CurA, CurB
and △X are in “s” and 1/△X is in “Hz”.
Hz: when this unit is selected, in the measurement results, CurA, CurB and
△X are in “Hz” and 1/△X is in “s”.
°: when this unit is selected, in the measurement results, CurA, CurB and
△X are in “°”. At this point, CurA immediately changes to “0°”, CurB changes
to “360°” and △X changes to “360°” as soon as you press Set Cursor, no
matter where the cursor A and B currently are located.
%: when this unit is selected, in the measurement results, CurA, CurB and
△X are in “%”. At his point, CurA immediately changes to “0%”, CurB
changes to “100%” and △X changes to “100%” as soon as you press Set
Cursor, no matter where the cursor A and B currently are located.
When the cursor type is “Voltage”, press Vertical Unit to select “Source Unit” or
“%”.
Source Unit: when this unit is selected, in the measurement, the units of
CurA, CurB and △Y will automatically be set to the unit of the current
source.
%: when this unit is selected, in the measurement results, CurA, CurB and
△X are in “%”. At this point, CurA immediately changes to “0%”, CurB
changes to “100%” and △X changes to “100%” as soon as you press Set
Cursor, no matter where the cursor A and B currently are located.
4. Adjust the Cursors Position
Adjust cursor A: press CursorA and use to adjust the position of cursor
A. During the adjustment, the measurement result will change accordingly.
The adjustable range is limited within the screen.
Adjust cursor B: press CursorB and use to adjust the position of cursor
B. During the adjustment, the measurement result will change accordingly.
The adjustable range is limited within the screen.
Adjust cursor A and B at the same time: press CursorAB and use to
adjust the position of cursor A and B at the same time. During the
adjustment, the measurement results will change accordingly. The
adjustable range is limited within the screen.
