12 Store and Recall RIGOL

DS6000 User’s Guide 12-7

2. Load the specified type of file in the internal memory.

1) Press SAVE  Storage to select "Traces" and then press Load to turn on

the interface as shown in Figure c. Use to select "Local Disk" and then

press down

to open the local disk.

Figure c

2) Use to select the desired file to be loaded and press Load to load the

file selected.
