RIGOL Chapter 2 Front Panel Operation
User’s Guide for DSA800/E Series
2-80
this menu. You can use the numeric keys, knob or direction keys to modify this
parameter.
Note: If the frequencies at Marker1 and Marker2 are the same, the two vertical
lines will overlap with the red vertical line corresponding to Marker2 being
displayed at the upper layer.

Rigol DSA815 Specifications

General

Frequency Range	9 kHz to 1.5 GHz
Input Impedance	50 Ω
Input Connector	N-type female
Weight	4.25 kg
Power Supply	100-240 V AC, 50/60 Hz
Phase Noise	-80 dBc/Hz @ 10 kHz offset
Amplitude Accuracy	±1.5 dB
Display	8 inch LCD (800x480 pixels)
Video Bandwidth (VBW)	1 Hz to 3 MHz
Maximum Input Level	+20 dBm
Interfaces	USB, LAN
Resolution Bandwidth (RBW)	100 Hz to 1 MHz
Dimensions	361 mm x 178 mm x 128 mm
