RIGOL Chapter 2 Front Panel Operation
User’s Guide for DSA800/E Series
2-124
1. print
Print the current screen according to print parameter settings when the
printer has been successfully installed and is in idle state.
2. Resume
Resume the print task that has been paused.
3. Cancel
Stop the current print task.
4. Orientation
Set the print orientation to “Landscape” or “Portrait” and the default is
“Landscape”.
5. Page Size
Set the page size to “Default”, “A4”, “A5”, “A6” or “B5”. When “Default” is
selected, the page size depends on the printer currently connected.
6. Inverted
Turn on or off the inverted print and the default is “Off”.
7. Palette
Set the print color to “Gray” or “Color” and the default is “Gray”.
8. Copies
Set the print copies and the default is 1. The range available is from 1 to 999.
9. Date Print
Turn on or off the date print and the default is “Off”. When it is turned on, the
file printed will contain the system date.
10. Qualities
Set the print quality to “Normal”, “Draft”, “Fine” or “Default”. When “Default” is
selected, the quality depends on the printer connected.
Tip:
“Fine” printing may consume more ink than others.

Rigol DSA815 Specifications

General

Frequency Range	9 kHz to 1.5 GHz
Input Impedance	50 Ω
Input Connector	N-type female
Weight	4.25 kg
Power Supply	100-240 V AC, 50/60 Hz
Phase Noise	-80 dBc/Hz @ 10 kHz offset
Amplitude Accuracy	±1.5 dB
Display	8 inch LCD (800x480 pixels)
Video Bandwidth (VBW)	1 Hz to 3 MHz
Maximum Input Level	+20 dBm
Interfaces	USB, LAN
Resolution Bandwidth (RBW)	100 Hz to 1 MHz
Dimensions	361 mm x 178 mm x 128 mm
