Rigol DSA815 User Manual

Chapter 2 Front Panel Operation RIGOL
User’s Guide for DSA800/E Series
2-125
11. File Type
Set the printing file type to “Default” or “Exif/JPEG”. When “Default” is
selected, the type depends on the printer currently connected.
Tip:
The analyzer can automatically identify the characteristics of the printer,
such as the page size, during the printer installation. If some
configuration is not supported by the current printer, the corresponding
menu in the analyzer is invalid. For example, if the current printer does
not support color printing, the “Color” option in the Palette menu is
invalid.

Rigol DSA815 Specifications

General

Frequency Range	9 kHz to 1.5 GHz
Input Impedance	50 Ω
Input Connector	N-type female
Weight	4.25 kg
Power Supply	100-240 V AC, 50/60 Hz
Phase Noise	-80 dBc/Hz @ 10 kHz offset
Amplitude Accuracy	±1.5 dB
Display	8 inch LCD (800x480 pixels)
Video Bandwidth (VBW)	1 Hz to 3 MHz
Maximum Input Level	+20 dBm
Interfaces	USB, LAN
Resolution Bandwidth (RBW)	100 Hz to 1 MHz
Dimensions	361 mm x 178 mm x 128 mm
