Chapter 2 Front Panel Operation RIGOL
User’s Guide for DSA800/E Series
When the copy path is the same as the paste path and the current path
has contained a file or folder with the same name, the corresponding
copy file with the “dup” prefix is generated after performing the paste
operation.
When the copy path is different from the paste path and the current path
has contained a file or folder with the same name,
— Replace file: press this key to replace the original file or folder.
— Cancel: press this key to cancel the paste operation.
Note: This operation is only available when the USB storage device connected
is recognized by the analyzer.
3. Apply To
Apply the state file selected in the external memory to the specified
user-defined configuration (User1 to User6).
4. Browser
A shortcut key. Refer to “Browser”.
5. Expand Dir
A shortcut key. Refer to “Expand Dir”.
6. Collapse Dir
A shortcut key. Refer to “Collapse Dir”.
Create Dir
Create a folder. Note that the length of the folder name is limited to 48 characters.
Press this key to enter the filename editing interface and refer to “
To Input
Filename” to edit the folder name. Then, press Save to create an empty folder
under the current directory.
Note: This operation is only available when the USB storage device connected is
recognized by the analyzer.
