RIGOL Chapter 2 Front Panel Operation
User’s Guide for DSA800/E Series
Disk Info
View the disk information, including the disk name, type, file system, the used
space and the total space.
Note: This menu is available only when external storage device is selected.
Name Prefix
1. Prefix Switch
Enable or disable the edited prefix name. The input box will automatically load
the prefix name after you press Save when Prefix Switch is set to “On”.
2. Edit Prefix
Edit the desired prefix name using the numeric keyboard. Up to 15 characters
can be entered.
System Update
Press this key to update the analyzer software after selecting the update file in the
USB storage device.
