Rigol RSA3000E Series User Manual

Chapter 2 Functions of the Front Panel of GPSA RIGOL
RSA3000E User Guide 2-93
Auto Trig
Off, 100 ms
Slope
Positive
Trig Delay
Off, 1 us
Trigger Level
-25 dBm
Trace
Selected Trace
Trace1
Trace Type
Clear Write
Trace Det
Pos Peak
Detector Auto
On
Trace Update
On
Trace Display
On
Math Function
Off
Op1
Trace5
Op2
Trace6
Offset
0 dB
Reference
0 dBm
TG
[1]
Output
Off
Amplitude
-40 dBm
Amplitude Offset
0 dB
Normalize
Off
Reference Level
10 dB
Reference Position
100%
Reference Trace
Off
Mode Setup
Global CF
On, 1.5 GHz
Meas
[2]
Measurement Function
Swept SA Measurement
VSWR
Off
Measure Setup
[2]
Swept SA Measurement
Avg Number
100
Avg Mode
Log
Avg State
On
Test Limits
Off
Select Limit
Limit1
Limit State
Off
Test Trace
Trace1
Limit Type
Upper
X to CF
Fixed
Y to Ref
Fixed
Margin
Off, 0 dB
Frequency
0 Hz
Amplitude
0 dBm
