Rigol RSA3000E Series User Manual

Chapter 5 Functions of the Front Panel of VSA RIGOL
RSA3000E User Guide 5-45
Shortcut Key
Auto Tune
In VSA mode, the Auto Tune function is disabled.
Preset
Recalls the preset setting and restores the system settings of the analyzer to a
specified status.
Remarks:
 To set the preset type, press System  Preset  Preset Type. The available
types include "Factory" or any one of items from "User1" to "User6".
 Press Preset to recall the factory settings listed in the following table (except
items specified in Note [1]) or user-defined settings.
Parameter Name
VSA Parameter Value
FREQ
Center Freq
1 GHz
Start Freq
998.4375 MHz
Stop Freq
1.0015625 GHz
CF Step
Auto, 312.5 kHz
SPAN
X Scale
Auto
Ref Value
0 sym
Width
50 sym
Ref Position
Left
Copy X Scale
to Trace 1
AMPT
Ref Value
0
Scale/Div
300 m
Range
20 dBm
X Axis Unit
Peak
Copy Y Scale
to Trace 1
BW
FFT Window
Flat Top
Trigger
Source
Free Run
Slope
Positive
Delay
Off, 1 us
Power
0 dBm
