Chapter 2 Functions of the Front Panel of GPSA RIGOL
RSA3000E User Guide 2-11
press Rename to rename the file.
Quick Print
If the printer has been successfully installed, press this key to quickly print the
currently displayed screen image.
Print
Prints the current screen according to print parameter settings when the printer has
been successfully installed and is in idle state.
Printer Setup
1. Printer Parameters
1) Page Size
Sets the page size for printing. When "Default" is selected, the page size
depends on the printer currently connected.
2) Quality
Sets the printed screen quality.
3) Color
Sets the print color to Color, Mono, Inverse, or Inverse-Mono.
4) Orientation
Sets the print orientation to "Landscape" or "Portrait".
5) Adjust
Sets the print border to be Adaptive, Non-Adpt, and Hold-Min.
6) Counts
Sets the print copies and the default is 1. The range available is from 1 to
99.
7) Border
Turns on or off the border.
In addition, you can preview the print page, and set to print the image or the
text in All page, 1/2, 1/4, or 1/9 page.
2. Add Device
Queries and adds a printer. Inputs the IP address of the printer, the
