RIGOL Chapter 2 Functions of the Front Panel of GPSA
2-18 RSA3000E User Guide
file is saved to be "abc.csv". After that, press the key again, another file is
saved automatically with the filename "abc1.csv".
2. Save As
Press this key and then use the numeric keypad on the front panel to input the
filename. Then, press Save to save the corresponding Limit file.
You can also touch the screen or use the mouse to tap or click the Save As
menu, and then input the filename with the keypad.
3. Select Limit
Selects the limit line to be saved. You can select any single limit line from Limit1
to Limit6.
Screen Image
Press Screen Image to enter the screen saving menu.
1. Save
Press this key to save the current screen image in the default filename or
user-defined filename.
The default filename is determined by the following methods:
 If you haven't input a filename by pressing the Save As key, its default
filename is screen<n>.jpg. Wherein, n refers to the file number of the
filenames that are named based on the naming mode in the current file
directory. The value of <n> is the existing maximum file number plus 1.
 If you have pressed the Save As key to input the filename abc, then the
file is saved to be "abc.jpg". After that, press the key again, another file is
saved automatically with the filename "abc1.jpg".
2. Save As
Press this key and then use the numeric keypad on the front panel to input the
filename. Then, press Save to save the corresponding Screen Image file.
You can also touch the screen or use the mouse to tap or click the Save As
menu, and then input the filename with the keypad.
3. Screenshot Info
1) Format
Press this key to select the file format of the current screen image to be
"JPEG", "BMP", or "PNG".
