Rigol RSA3000E Series User Manual

Chapter 3 Functions of the Front Panel of RTSA RIGOL
RSA3000E User Guide 3-31
Table 3-19 Bottom Hue Position
Parameter
Remarks
Default
0
Range
0 to Min (90%, reference
position value - 10%)
Unit
None
Knob Step
1
Left/Right Arrow Key Step
Up/Down Arrow Key Step
7. Auto Adjust Hue
Auto adjusts the reference hue position and bottom hue position based on the
highest amplitude value found in the spectrogram and the lowest amplitude
value found in the spectrogram, respectively. The reference hue position is set to
be the highest amplitude value, and the bottom hue position to be the lowest
amplitude value.
SSC
The SSC function can continuously capture the signals with abrupt changes of power.
1. Max Hold
Enables or disables the Max Hold. When the Max Hold is enabled, the signal
captured each time will be compared with the last captured signal, whichever is
the larger value will be displayed as the max hold trace.
2. Reset
Clears the existing measurement results.
3. Mark Line1 State
Enables or disables Mark Line1. When Mark Line1 is enabled, a blue vertical line
is displayed in the basic measurement window.
4. Mark Line1
Displays or sets the frequency value at Mark Line1. You can use the numeric
keys, the knob, or arrow keys to modify the frequency value at Mark Line1; you
can also use the touch screen to modify the value.
5. Mark Line2 State
Enables or disables Mark Line2. When Mark Line2 is enabled, a red vertical line is
displayed in the basic measurement window.
6. Mark Line2
Displays or sets the frequency value at Mark Line2. You can use the numeric
keys, the knob, or arrow keys to modify the frequency value at Mark Line2; you
