RIGOL Chapter 4 Functions of the Front Panel of EMI
4-14 RSA3000E User Guide
External 2
Press Input/Output ïƒ Ext Trigger2 to select "In". Then, an external signal is
input via the [TRIGGER IN/OUT] connector on the rear panel. When the signal
meets the set trigger conditions, trigger signals are generated.
Note: The input signal frequency on the external trigger interface should not be
greater than 1 MHz.
1. Slope
Sets the trigger polarity for External Trigger 2 to "POS" or "NEG".
2. Delay State
Enables or disables the trigger delay function. After the trigger delay function is
enabled, you can set the trigger delay time.
3. Delay Time
Sets the time interval during which the instrument waits to start the sweep
operation after the trigger signal that meets the trigger conditions is generated.
You can use the numeric keys, the knob, or arrow keys to modify this parameter;
you can also use the touch screen to modify the parameter.
Table 4-12 Trigger Delay Time
trigger delay/100, Min = 1 μs
Left/Right Arrow Key Step
Hold-off State
Turns on or off the trigger hold-off function.
Hold-off Time
Sets the hold-off time between trigger signals. You can use the numeric keys, the
knob, and the arrow keys on the front panel to modify this parameter; also you can
modify it on the touchscreen.
When the trigger conditions are met, the trigger occurs. Then, the delay begins, and
