Rigol RSA3000E Series User Manual

Chapter 5 Functions of the Front Panel of VSA RIGOL
RSA3000E User Guide 5-9
Table 5-10 Range
Parameter
Remarks
Default
20 dBm
Range
-15 dBm to 25 dBm
Unit
dBm, -dBm, V, mV, uV
Knob Step
1 dBm
Left/Right Arrow Key Step
Up/Down Arrow Key Step
10 dBm
Y Axis Unit
Sets the unit of the Y-axis unit to Peak, RMS, or Power.
Remarks:
 The Y-axis unit is valid when the data source is "CaptureTime" or
"CaptureSpectrum". After a unit is selected, the instrument will process the
signal data according to the currently selected unit. At this time, you can
observe the changes of the trace in the selected trace window, but the display of
the graticule scale remains unchanged.
 For other data sources, if the trace format is "Log Mag", the default unit is dB; if
you select "Wrap Phase" or "Unwrap Phase", the default unit is deg. Other trace
format data are normalized, so they do not have the unit.
Table 5-11 Y Axis Unit
Trace
Data
Y-axis
Unit
LinearMag LogMag I(Real) Q(Imaginary) WrapPhase
unWrap
Phase
Capture
Time
Peak
V
dBVpk
V
V
deg
deg
RMS
Vrms
dBVrms
Vrms
Vrms
deg
deg
Power
W
dBm
V
V
deg
deg
Capture
Spectrum
Peak
Vpk
dBVpk
Vpk
Vpk
deg
deg
RMS
Vrms
dBVrms
Vrms
Vrms
deg
deg
Power
W
dBm
Vpk
Vpk
deg
deg
Copy Y Scale
Copies the Y scale of the current trace to other traces. The available ranges can be
Trace1 through Trace4.
Note: Only when the X-axis and Y-axis units of different traces are the same, the
Y-axis scale information can be copied between different traces.
