Chapter 5 Functions of the Front Panel of VSA RIGOL
RSA3000E User Guide 5-25
part of data in the vertical axis.
8. Constellation
Same as I-Q, the difference is that only symbol points are displayed with no
connecting lines.
9. Q-Eye
Indicates the eye diagram for quadrature signal.
10. I-Eye
Indicates the eye diagram for in-phase signal.
Trace Setup
Sets the display of the digital demodulation trace data.
1. Eye Length
Sets the width of the eye diagram, and which is displayed in the symbol period.
Note: This menu is only valid when the trace format is "Q-Eye" or "I-Eye".
Table 5-20 Eye Length
1
Left/Right Arrow Key Step
2. Symbol Format
Sets the display format of the symbol data. You can select "Hex" or "Binary".
Note: The menu is valid when the data source is "Symbol".
3. Trace Det
Sets the detector for the current trace when the "RT Trace" data source is
selected. The available trace detectors include Pos Peak, Neg Peak, Average,
and Sample.
