Rion VM-83 - Single and All Unit Control

57
Serial Interface
- When INPUT SELECT is set to ACCELEROMETER, PREAMP1,
PREAMP2
(*0 = HPF 1 Hz, *1 = HPF 3 Hz, *2 = HPF 10 Hz and higher)
Sensitivity
Measurement
n =0 n = 1 n = 2 n = 3 n = 4 n = 5 n = 6 n = 7
mode
0.030
ACC 3 10 30 100 300 1000 3000 10000
VEL 30 100 300 1000 3000 10000 - -
0.999
DISP*
0
- 10 30 100 300 1000 3000 10000
pC/(m/s
2
)
DISP*
1
3 10 30 100 300 1000 3000 10000
DISP*
2
0.3 1 3 10 30 100 300 1000
1.00
ACC 0.3 1 3 10 30 100 300 1000

VEL 3 10 30 100 300 1000 - -
9.99
DISP*
0
- 1 3 10 30 100 300 1000
pC/(m/s
2
)
DISP*
1
0.3 1 3 10 30 100 300 1000
DISP*
2
0.03 0.1 0.3 1 3 10 30 100
10.0
ACC 0.03 0.1 0.3 1 3 10 30 100

VEL 0.3 1 3 10 30 100 - -
99.9
DISP*
0
- 0.1 0.3 1 3 10 30 100
pC/(m/s
2
)
DISP*
1
0.03 0.1 0.3 1 3 10 30 100
DISP*
2
0.003 0.01 0.03 0.1 0.3 1 3 10
- When INPUT SELECT is set to SERVO , SERVO
Sensitivity
Measurement
n = 1 n = 2 n = 3 n = 4 n = 5
mode
0.100 ACC 10 30 100 300 1000
 VEL 1 3 10 30 100
0.999 DISP 0.1 0.3 1 3 10
UNT n Set measurement mode
n = 0 ACC (acceleration)
n = 1 VEL (velocity)
n = 2 DISP (displacement)
