Rion VM-83 - Dimensional Drawing

82
Specifications
- Accelerometer sensitivity 1.00 to 9.99 pC/(m/s
2
)
Acceleration 0.3, 1, 3, 10, 30, 100, 300, 1000 m/s
2
Velocity 3, 10, 30, 100, 300, 1000 mm/s
Displacement 1, 3, 10, 30, 100, 300, 1000 mm (HPF 1 Hz)
Displacement 0.3, 1, 3, 10, 30, 100, 300, 1000 mm (HPF 3 Hz)
Displacement 0.03, 0.1, 0.3, 1, 3, 10, 30, 100 mm (HPF 10 Hz
or higher)
- Accelerometer sensitivity 10.0 to 99.9 pC/(m/s
2
)
Acceleration 0.03, 0.1, 0.3, 1, 3, 10, 30, 100 m/s
2
Velocity 0.3, 1, 3, 10, 30, 100 mm/s
Displacement 0.1, 0.3, 1, 3, 10, 30, 100 mm (HPF 1 Hz)
Displacement 0.03, 0.1, 0.3, 1, 3, 10, 30, 100 mm (HPF 3 Hz)
Displacement 0.003, 0.01, 0.03, 0.1, 0.3, 1, 3, 10 mm
(HPF 10 Hz or higher)
Servo accelerometer
Acceleration 10, 30, 100, 300, 1000 m/s
2
Velocity 1, 3, 10, 30, 100 mm/s
Displacement 0.1, 0.3, 1, 3, 10 mm
Vibration frequency range
Piezoelectric accelerometer
Acceleration 1 Hz to 20 kHz ±5%
(AC output: 15 kHz to 20 kHz )
Velocity 1 Hz to 3 Hz ±10%, 3 Hz to 3 kHz ±5%
Displacement 1 Hz to 3 Hz ±20%, 3 Hz to 500 Hz ±10%
Servo accelerometer
Acceleration 0.1 Hz to 100 Hz ±5%
Velocity 0.1 Hz to 0.3 Hz ±10%, 0.3 Hz to 100 Hz ±5%
Displacement 0.1 Hz to 0.3 Hz ±20%, 0.3 Hz to 100 Hz ±10%
