40 • Viewing, Printing, Exporting, and Deleting Data
To view and perform desired operations with the alarm trend
les:
1. With the software already launched, click the Data control
button along the right side of the program window. The Data
window will appear.
2. If necessary, double-click the GX-2003 icon in the top of the
Data windows upper left frame to see the folders of
downloaded data.
3. Find your instrument by serial number, then click the
expanded view symbol (+) of or double-click the folder to
view the contents.The top folder is untitled and contains the
Calibration History folder. The rest of the folders contain
folders for the interval trend les, alarm trend les, and event
les and are named and organized by date (month/year).
4. Click the expanded view symbol (+) of or double-click the
dated folder whose contents you want to see.
5. Click on the Alarm Trend folder in the upper left frame. In the
upper right frame of the Data window, a list of le names will
Figure 27: Data Window - Selecting Alarm Trend Data Files
Double-click to
show data folders
Click to expand
folder
Click to show
alarm trend files
Alarm trend files
