RMG TME400-VMF User Manual

APPENDIX
MANUAL TME400-VCF · EN08 · July, 01
st
2021
107
Empty header ring buffer at the beginning after writing a new entry:
Storage index
0
Archive header (Position number 1) -> Actual header
1
empty
2
empty
3
empty
Ring buffer after the writing of four entries:
Storage index
0
Archive header (Position number 1)
1
Archive header (Position number 2)
2
Archive header (Position number 3)
3
Archive header (Position number 4) -> Actual header
Ring buffer after the writing of six entries:
Index
0
Archive header (Position number 5)
1
Archive header (Position number 6) -> Actual header
2
Archive header (Position number 3)
3
Archive header (Position number 4)
Content of an empty header:
Content
Data type
Value
Position number of the next archive
UINT16
0
Index of the oldest entry
UINT16
FFFFh
Index of the newest entry
UINT16
FFFFh
CRC16
UINT16
xxxxh
Content of the header after the writing of the first archive entry:
Inhalt
Data type
Value
Position number of the next archive
UINT16
1
Index of the oldest entry
UINT16
0
Index of the newest entry
UINT16
0
CRC16
UINT16
xxxxh
