Publication IASIMP-QS003B-EN-P - October 2009 75
Prepare the PanelView Plus Terminal Chapter 5
9. Select Close [F8] until
you return to the initial
configuration screen.
10. Select Reset [F8] to reset
the terminal, then
Yes [F7] to confirm.
Upgrade Terminal Firmware
Required for Terminals with Firmware Earlier than 4.00.09
If the firmware in your PanelView Plus terminal is earlier than 4.00.09, you need to upgrade
the terminal firmware. You can download the firmware from this website:
http://support.rockwellautomation.com/ControlFlash/FUW.asp
To update the terminal firmware, launch FactoryTalkView Machine Edition software and
select Tools>Firmware Upgrade Wizard. Upgrade the firmware in the terminal by using the
RSLinx Enterprise network connection.
