44 Rockwell Automation Publication ICSTT-RM406J-EN-P - February 2021
Chapter 5 Troubleshooting and Rectifying Module Faults
Procedure for Installation of a Second and Third Processor
The second and third processor modules must have the same firmware
version as the first processor. If the firmware revision is different upgrade the
firmware using the ControlFLASH™.
2.
All status indicators are off and after applying power the processor will show the following
status indications:
Healthy
Flashes RED for a second then goes GREEN as the module boots up (10-20
seconds)
Ready Will stay OFF as the module boots up (10 to 20 seconds) then goes RED
Run Will stay OFF as the Module boots up (10 to 20 seconds) then goes RED
System Healthy Will stay OFF as the Module boots up (10 to 20 seconds) then goes GREEN
Force
Will stay OFF as the Module boots up (10 to 20 seconds) then stays OFF until
the module has educated.
Aux
Will stay OFF as the Module boots up (10 to 20 seconds) then depends on data
connection.
Serial 1
Will stay OFF as the Module boots up (10 to 20 seconds) then depends on data
connection
Serial 2
Will stay OFF as the Module boots up (10 to 20 seconds) then depends on data
connection
Ethernet 1
Will stay OFF as the Module boots up (10 to 20 seconds) then depends on data
connection
Ethernet 2
Will stay OFF as the Module boots up (10 to 20 seconds) then depends on data
connection
3.
Install a Program Enable Key. Download a correct application and push the FAULT RESET
button. When a valid application is downloaded the module shows the following indications:
Valid application downloaded
Healthy GREEN
Ready GREEN
Run RED to GREEN (Flashes GREEN as the module educates)
System Healthy GREEN
Force GREEN
Aux Off (Depends on application)
Serial 1 Depends on data connection
Serial 2 Depends on data connection
Ethernet 1 Depends on data connection
Ethernet 2 Depends on data connection
IMPORTANT
When inserting a second and third processor module they MUST
be inserted one at a time and allowed to educate before inserting
the next one.
Table 4 - Single Processor Module Installation Procedure (New Processor Module)
Step Task
