Rockwell Automation Publication ICSTT-RM406J-EN-P - February 2021 25
Chapter 3 Upgrading Controller Firmware
• The data is saved with the project so that next time the project is
opened you can view it.
6. To save data to a text file click Save As.
7. A window opens with a default text file name Version_Report.txt; Enter
your own file name and click Save.
Upgrade the processor
module firmware
Upgrade the processor module Recovery Mode firmware and then upgrade the
processor module firmware.
The processor module firmware upgrade process can be summarized as
follows:
1. Download software and firmware.
2. Install software.
3. Configure RSLinx Classic software.
4. Use ControlFLASH to upgrade firmware.
Download software and firmware
Download these items from the PCDC, rok.auto/pcdc:
• RSLinx Classic or RSLinx Classic Lite software, version 4.20.00 or later
Used by the ControlFLASH to communicate with the AADvance
controller over an Ethernet network.
• ControlFLASH Firmware Tools version 15.03.00 or later
Firmware update tool used for electronically updating firmware.
• T9110 Processor Module firmware files
• Firmware for T9110 Processor Module v1.040 (T9110_1.040.dmk)
• Firmware for T9110 Recovery Mode Processor Module version 1.001
(T9110_Recovery_Mode_1.001.103.dmk)
