Chapter 5 Connect the Kinetix 5300 Drive System
Table 43 - Kinetix MP, LDAT, LDC, and LDL Motor Power Cable Compatibility
Table 44 - Kinetix TL and TLY Motor Power/Brake Cable Compatibility
Refer to Motor Power Connector Wiring on page 79 for motor power and brake
connector specifications.
Table 45 - Legacy Motor Power Cables
Table 46 - Induction Motor Power Cable Specifications
Motor/Actuator 
Cat. No.
Motor Power Cat. No.
(1)

(with brake wires)
Motor Power Cat. No.
(1)

(without brake wires)
MPL-A/B15xxx-xx7xAA, MPL-A/B2xxx-xx7xAA,
MPL-A/B3xxx-xx7xAA, MPL-A/B4xxx-xx7xAA, 
MPL-A/B45xxx-xx7xAA, MPL-A/B5xxx-xx7xAA, 
MPL-B6xxx-xx7xAA
2090-CPBM7DF-xxAAxx (standard) or
2090-CPBM7DF-xxAFxx (continuous-flex)
2090-CPWM7DF-xxAAxx (standard) or
2090-CPWM7DF-xxAFxx (continuous-flex)
MPM-A/Bxxxx, MPF-A/Bxxxx, MPS-A/Bxxxx
MPAS-A/Bxxxx1-V05SxA, 
MPAS-A/Bxxxx2-V20SxA
MPAI-A/Bxxxx, MPAR-A/B3xxx,

MPAR-A/B1xxx and MPAR-A/B2xxx (series B)
MPAS-Bxxxxx-ALMx2C
LDAT-Sxxxxxx-xDx 
LDAT-Sxxxxxx-xBx 
LDC-Cxxxxxx 
LDL-xxxxxxx
—
(2)

(1) For cable specifications, refer to the Kinetix Rotary and Linear Motion Cable Specifications Technical Data, publication KNX-TD004.
(2) These devices do not include a brake option.
Motor/Actuator 
Cat. No.
Motor Power Cat. No.
(1)

(with brake wires)
Motor Power Cat. No.
(1)

(without brake wires)
Brake Cat. No.
(1)
TLY-Axxxx 2090-CPBM6DF-16AAxx (standard) 2090-CPWM6DF-16AAxx (standard)
—
Brake conductors are included in
the power cable.
TL-Axxxx — 2090-DANPT-16Sxx 2090-DANBT-18Sxx
(1) For cable specifications, refer to the Kinetix Rotary and Linear Motion Cable Specifications Technical Data, publication KNX-TD004.
Motor Cable Description Motor Power Cat. No.
Standard
Power/brake, threaded 2090-XXNPMF-xxSxx
Power-only, bayonet 2090-XXNPMP-xxSxx
Continuous-flex
Power/brake, threaded 2090-CPBM4DF-xxAFxx
Power-only, threaded 2090-CPWM4DF-xxAFxx
Power-only, bayonet 2090-XXTPMP-xxSxx
Cable Manufacturer Cable Series Voltage Rating Temperature Rating Cable Length, max
Belden 29505-29507
1000V 90 °C (194 °F) 50 m (164 ft)Lapp Group ÖLFEX VFD XL
SAB VFD XLPE TR
