18 Rockwell Automation Publication 2715P-UM001C-EN-P - March 2019
Chapter 1 Overview
SD and SDHC accessory cards in Tabl e 6 have been designed to meet industrial
robustness and environmental requirements. Rockwell Automation recommends
you use these accessory cards with the terminal to help reduce the chances of
corruption. Studio 5000 View Designer software requires the following for SD
cards that are inserted into the HMI device:
• 4 GB of free space
• A supported SDHC card type, preferably one listed in Table 6
• An environmental rating for the PanelView 5000 environment
• A supported format of either FAT32 or ext3
Ethernet Cables
See the Industrial Ethernet Media Brochure, publication 1585-BR001B, for
recommended Ethernet cables and media solutions.
Table 5 - Power Supplies and Power Terminal Blocks
Cat. No. Description Quantity
1606-XLP95E DIN-rail power supply, 24…28V DC output voltage, 95 W 1
1606-XLP100E DIN-rail power supply, 24…28V DC output voltage, 100 W 1
2711P-RSACDIN DIN-rail power supply, AC-to-DC, 100…250V AC, 50…60 Hz 1
2711P-RTBDSP 3-pin DC power terminal block (black with white labels for +, –, and GND) 10
Table 6 - Secure Digital (SD) Cards
(1)
(1) To help reduce the chance of corruption when you use SD Cards or USB drives with the terminal, Rockwell Automation
recommends that you use only the above SD card catalog numbers.
Cat. No. Description Quantity
1784-SD1 1-GB SD card 1
1784-SD2 2-GB SD card 1
1784-SDHC8 8-GB SDHC card 1
1784-SDHC32 32-GB SDHC card 1
2711C-RCSD USB to SD adapter for SD card 1
Table 7 - Mounting Hardware
Cat. No. Description Quantity
2711P-RMCP
(1)
(1) Catalog number 2711P-RMCP mounting levers are used with the PanelView 5510 terminals. Do not use gray mounting levers; they
are not compatible with PanelView 5510 terminals.
Mounting levers (black) 16
Table 8 - Battery Replacement
Cat. No. Description Quantity
2711P-RY2032 Lithium coin cell battery, CR2032 equivalent 1
