Chapter 2 Install the PanelView 5510 Terminal
Panel Guidelines
The terminals are panel-mounted devices that mount in the door or wall of a
NEMA, UL Type, or IP rated enclosure:
• Enclosure panels must meet the panel thickness requirements in Table 13
on page 28.
• The material strength and stiffness of the panel must be sufficient to hold
the terminal and maintain an appropriate seal against water and dust.
• The panel surface must be flat and free of imperfections to maintain an
adequate seal and NEMA, UL Type, or IP ratings.
Panel Cutout Dimensions
Use the template that is shipped with your terminal to mark the cutout
dimensions.
Table 11 - PanelView 5510 - Panel Cutout Dimensions
Terminal Size Input Type Height, mm (in.) Width, mm (in.)
6.5-in. Keypad and touch 142 (5.59) 237 (9.33)
Touch 142 (5.59) 184 (7.24)
7-in. Touch 150 (5.9) 210 (8.25)
9-in. Touch 162 (6.38) 252 (9.92)
10.4-in. Keypad and touch 224 (8.82) 335 (13.19)
Touch 224 (8.82) 269 (10.59)
12.1-in. Touch 218 (8.58) 312 (12.28)
15-in. Keypad and touch 290 (11.42) 418 (16.46)
Touch 290 (11.42) 353 (13.90)
19-in. Touch 383 (15.08) 457 (17.99)
