Overview of Drive Chapter 1
IEEE 519 Harmonic Guidelines
(6)
IEEE 519 - 1992 Compliant
VFD Noise Level < 85 dB (A)) per OSHA Standard 3074
Regenerative Braking Capability Inherent – No Additional Hardware or Software Required
Flying Start Capability Yes – Able to Start into and Control a Spinning Load in Forward or Reverse
Direction
Operator Interface 10” Color Touchscreen – Cat# 2711P-T10C4A9 (VAC)
Built-in PDF viewer
Redesigned PanelView Plus 6 Logic Module with 512 Mb of memory
Languages English, French, Spanish, Portuguese, German, Chinese, Italian, Russian, and
Polish
Control Power 220/240V or 110/120V, Single phase - 50/60 Hz (20 A)
External I/O 16 Digital Inputs, 16 Digital Outputs
External Input Ratings 50…60 Hz AC or DC
120…240V – 1 mA
External Output Ratings 50…60 Hz AC or DC
30…260V – 1 A
Analog Inputs Three Isolated, 4…20 mA or 0…10V (250 Ω)
Analog Resolution Analog input 12 Bit (4…20 mA)
Internal parameter 32 Bit resolution
Serial Communication 16 Bit resolution (.1Hz)
(Digital Speed Reference)
Analog Outputs One Isolated, Eight Non-isolated,
4…20 mA or 0…10V (600 Ω)
Communication Interface Ethernet IP™/DPI™
Scan Time Internal DPI – 2 ms min., 4 ms max.
Communications Protocols
(Optional)
DeviceNet® ControlNet®
Ethernet I/P Lon Works
Dual-port Ethernet I/P Can Open
Profibus RS485 HVAC
Modbus RS485 DF1
Interbus RS232 DF1
USB
Enclosure NEMA 1 (standard) IP21 (IEC)
NEMA 12 (optional) IP42 (IEC)
Lifting Device Standard / Removable
Mounting Arrangement Mounting Sill Channels
Structure Finish Epoxy Powder – Paint
Exterior Sandtex Light Grey (RAL 7038) – Black (RAL 8022)
Internal – Control Sub Plates – High Gloss White (RAL 9003)
Interlocking Key provision for customer input Disconnecting Device
Corrosion Protection Unpainted Parts (Zinc Plated / Bronze Chromate)
Ambient Temperature 0…40 °C (32…104 °F) / 0…50 °C (32…122 °F) - optional
Fiber Optic Interface Rectifier – Inverter – Cabinet (Warning / Trip)
Door Filter Painted Defuser with Matted Filter Media
Table 1 - General Design Specifications (Continued)
