Rockwell Automation Publication 7000L-UM301F-EN-P - March 2020 355
Component Definition and Maintenance Chapter 5
The Analog Control Board (ACB) receives all of the Analog Signals from the
drive’s internal components. This includes the current and voltage feedback
signals. The boards also have isolated Digital I/O for e-stops, contactor control
and status feedback. All of the test points for the currents, system voltages,
control voltages, and flux are on these boards.
Table 23 - Connectors on Analog Control Board
ACB Connectors Description
ACB-J1 Control I/O & Control Power Monitor
ACB-J2 Line current inputs, CT2U, CT2W
ACB-J3 Line current inputs, CT3U,CT3W
ACB-J4 Line current inputs, CT4U,CT4W
ACB-J5 Motor current inputs, HECSU,HECSW
ACB-J6 DClink current inputs, HECSDC1, HECDC2
ACB-J7 Ground fault & CMC Neutral current inputs, GFCT, INN
ACB-J8 Isolated & Non-isolated analog inputs, AIN1,AIN2,AIN3 and Non-isolated outputs,
AOUT1AOUT2,AOUT3,AOUT4
ACB-J9 Air pressure inputs, AP0,AP1(input from TSP)
ACB-J10 Meter outputs, AOUT5,AOUT6,AOUT7,AOUT8 and Speed Pot input, AIN0
ACB-J11 Communication connections, printer outputs
ACB-J12 Communication connections, PanelView
ACB-J13 DC power supplies, XIO(+24V),+/-15V,+/-24V,+5V
ACB-J14 DC power supply monitoring, 5V1,5V2, DC-BUS
ACB-J15 DC-ABUS +56V output monitoring in UPS option
ACB-J16 DPI interface
ACB-J17 Communication connections, scan ports
ACB-J18 DC fail signal monitoring
ACB-J19 DC fail signal monitoring
ACB-J20 DC fail signal monitoring
ACB-J21 DC fail signal monitoring
ACB-J22 Communication connection, XIO link CAN interface
ACB-J23 Communication connection, parallel drive
ACB-J24 UPS fail signal monitoring
ACB-J25 Line voltage synchronous transfer feedback voltage inputs VSA,VSB,VSC
ACB-J26 Motor & line DC link and Neutral Point Voltage inputs
ACB-J27 AC Motor & Line voltage feedback inputs
ACB-J28 Encoder interface
ACB-J30 DPM connection, A/D SUB system
ACB-J31 DPM connection, DACs serial data
ACB-J32 DPM power supply, +5V
ACB-J33 DPM connection, Faults & other I/O
ACB-J34 DPM connection, Encoder
