356 Rockwell Automation Publication 7000L-UM301F-EN-P - March 2020
Chapter 5 Component Definition and Maintenance
Table 24 - Test Points on Analog Control Board
Test points Name Description
TP1 Vuv Motor Voltage Feedback, UV
TP2 Vvw Motor Voltage Feedback, VW
TP3 Vwu Motor Voltage Feedback, WU
TP4 Iu Motor Current, HECSU
TP5 Iw Motor Current, HECSW
TP6 Vzs Zero Sequence Generation Motor side, VZS
TP7 Vn Motor Side Filter CAP Neutral Voltage, MFCN
TP8 V_pk Motor Over Voltage Detection for UVW
TP9 Vdci1 Motor Side DCLINK Voltage for Bridge #1, VMDC1
TP10 Vdci2 Motor Side DCLINK Voltage for Bridge #2, VMDC2
TP11 Vuvs Line Voltage Synchronous Feedback, VSAB
TP12 V2uv Line Voltage Feedback, 2UV
TP13 V2vw Line Voltage Feedback, 2VW
TP14 V2wu Line Voltage Feedback, 2WU
TP15 I2u Line current, CT2U
TP16 I2w Line current, CT2W
TP17 Vzs2 Zero Sequence Generation Line side, VZS2
TP18 Vn1 Line Filter CAP Neutral Voltage for Bridge #1, LFCN1
TP19 V2_pk AC over voltage detection for 2UVW
TP20 Vdcr1 Line side DCLINK Voltage for Bridge#1, VLDC1
TP21 Idc1 DCLINK current, HECSDC1
TP22 Vvws Line Voltage Synchronous Feedback, VSBC
TP23 V3uv Line Voltage Feedback, 3UV
TP24 V3vw Line Voltage Feedback, 3VW
TP25 V3wu Line Voltage Feedback, 3WU
TP26 I3u Line current, CT3U
TP27 I3w Line current, CT3W
TP28 Vzs3 Zero Sequence Generation Line side, VZS3
TP29 Vn2 Line Filter CAP Neutral Voltage for Bridge #2, LFCN2
TP30 V3_pk AC over voltage detection for 3UVW
TP31 Vdcr2 Line side DCLINK Voltage for Bridge#2, VLDC2
TP32 Idc2 DCLINK current, HECSDC2
TP33 Vwus Line Voltage Synchronous Feedback, VSCA
TP34 V4uv Line Voltage Feedback, 4UV
TP35 V4vw Line Voltage Feedback, 4VW
TP36 V4wu Line Voltage Feedback, 4WU
TP37 I4u Line current, CT4U
TP38 I4w Line current, CT4W
TP39 Vzs4 Zero Sequence Generation Line side, VZS4 (spare one)
