Rockwell Automation Publication 7000L-UM301F-EN-P - March 2020 357
Component Definition and Maintenance Chapter 5
TP40 Vnn CMC Neutral Voltage, VNN
TP41 Inn CMC Neutral current, INN
TP42 Ignd Ground Fault current, GFCT
TP43 Vspr Spare channel for inputs
TP44 Vmtrp Motor Over Voltage Detection set point
TP45 A+ Encoder A+ input
TP46 B+ Encoder B+ input
TP47 Z+ Encoder Z+ input
TP48 A- Encoder A-input
TP49 B- Encoder B- input
TP50 Z- Encoder Z- input
TP51 CP1 Control Power monitoring for channel 1
TP52 CP2 Control Power monitoring for channel 2
TP53 CP3 Control Power monitoring for channel 3
TP54 CP4 Control Power monitoring for channel 4
TP55 Vltrp AC Over Voltage Detection set point for 2UVW & 3UVW
TP56 AGND Analog ground
TP57 AGND Analog ground
TP58 AGND Analog ground
TP59 AGND Analog ground
TP60 +5V +5V DC power supply
TP61 +15V +15V DC power supply
TP62 -15V -15V DC power supply
TP63 +24V +24V DC power supply
TP64 -24V -24V DC power supply
TP65 24VCOM +/- 24V common
TP66 DGND Digital ground
TP67 AGND Analog ground
TP68 AP1 Analog Control Inputs, Air pressure input, AP1
TP69 AP0 Analog Control Inputs, Air pressure input, AP0
TP70 AIN1 Analog Control Input, AIN1
TP71 AIN2 Analog Control Input, AIN2
TP72 AIN0 Analog Control Input, AIN0
TP73 AIN3 Analog Control Input, AIN3
TP74 IPIS Input Isolating Switch
TP75 IPCS Input Contactor Status
TP76 IP Input Contactor Command
TP77 OPIS Output Isolating Switch
TP78 OPCS Output Contactor Status
TP79 OP Output Contactor Command
Test points Name Description
