Rockwell Automation Publication 7000L-UM301F-EN-P - March 2020 387
Component Definition and Maintenance Chapter 5
4. The display will change to ‘Select Group’ screen as shown in the picture
below. Now there are three ways to find the desired a parameter, (i) search
by group (select the group by pressing up or down arrow keys and then
press Enter key), (ii) search by Alphabetical order (press F7 key to move to
the letters screen from there you can search the parameter by highlighting
the first letter of the parameter and then pressing the Enter key), (iii) by
entering the parameter linear number (press F7 and then F5 for the Code).
In the following example we will select the parameter by using a Linear
number (i.e., we will enter the Code). For this follow the steps outlined
below.
Figure 320 - Select Group
5. Press F7 [LIST]. The display will change to ‘Select Letter’ screen as
shown in the picture below.
Figure 321 - Select Letter
