Rockwell Automation Publication 7000L-UM301F-EN-P - March 2020 41
Drive Installation Chapter 2
Figure 17 - CPVC Pipe Splices (Capacitor #2 not shown for clarity)
Figure 18 - Typical Strap Wrench (not supplied) used to tighten unions on CPVC pipe splices
Pipe Splice #1
Capacitor
Cabinet
DC Link
Choke Cabinet
Pipe Splice #2
