62 Rockwell Automation Publication 7000L-UM301F-EN-P - March 2020
Chapter 2 Drive Installation
Figure 51 - Low Voltage Tub Compartment
ANALOG
CONTROL
BOARD
Analog Control Board Drive Processor
Module (DPM)
Tach Feedback
Circuit Board
DC/DC Power Supply Fiber Optic Interface Boards
