Rockwell Automation Publication 7000L-UM301F-EN-P - March 2020 63
Drive Installation Chapter 2
Figure 52 - Converter Cabinet Components (4160V AFE shown)
Ground Bus
Isolated Gate Drive
Power Supplies
(IGDPS)
Inverter Modules
Rectifier Modules
Coolant Piping
