54 / 207 - EN -
12.3.2. Assembly
Step Description Illustration
1
Preparing the pottery wheel:
The worktop as well as the location
bolts and the storage inside the
plastic protection tube must be clean
and dry.
2
Fit the clean splash pan.
Attention:
The drain hose must be
positioned centrally over the hole
in the worktop.
The hose must not be kinked.
3
Put on the wheel head.
Attention:
Make sure that the wheel head
can be placed on the locating
bolt without any effort or tilting.
Make sure that the carriers on
the machine fit exactly into the
recesses in the wheel head.
4
Insert and tighten the screw in the
centre.
Tool:
8 mm Allen key
(included in the pottery wheel's scope
of delivery)
Torque:
10 Nm
