Chapter 2 Pins and Connections
MC9S08QE128 MCU Series Reference Manual, Rev. 2
Freescale Semiconductor 37
41 33 25 23 17 PTB1 KBI1P5 TxD1 ADP5
42 34 26 24 18 PTB0 KBI1P4 RxD1 ADP4
43————PTJ3
44————PTJ2
45 35 — — — PTF3 ADP13
46 36 — — — PTF2 ADP12
47 37 27 25 19 PTA7 TPM2CH2 ADP9
48 38 28 26 20 PTA6 TPM1CH2 ADP8
49 39 29 — — PTE4
50 40 30 27 — V
DD
51 41 31 28 — V
SS
52 42 — — — PTF1 ADP11
53 43 — — — PTF0 ADP10
54————PTJ1
55————PTJ0
56 44 32 29 — PTD4 KBI2P4
57 45 33 30 21 PTD3 KBI2P3
SS2
58 46 34 31 22 PTD2 KBI2P2 MISO2
59 47 35 32 23 PTA3 KBI1P3 SCL1
1
ADP3
60 48 36 33 24 PTA2 KBI1P2 SDA1
1
ADP2
61 49 37 34 25 PTA1 KBI1P1 TPM2CH0 ADP1
3
ACMP1-
3
62 50 38 35 26 PTA0 KBI1P0 TPM1CH0 ADP0
3
ACMP1+
3
63 51 39 36 27 PTC7 TxD2 ACMP2-
64 52 40 37 28 PTC6 RxD2 ACMP2+
65————PTG7 ADP23
66————PTG6 ADP22
67————PTG5 ADP21
68————PTG4 ADP20
69 53 41 — — PTE3
SS1
2
70 54 42 38 — PTE2 MISO1
2
71 55 — — — PTG3 ADP19
72 56 — — — PTG2 ADP18
73 57 — — — PTG1
74 58 — — — PTG0
75 59 43 39 — PTE1 MOSI1
2
76 60 44 40 — PTE0 TPM2CLK SPSCK1
2
77 61 45 41 29 PTC5 TPM3CH5 ACMP2O
78 62 46 42 30 PTC4 TPM3CH4 RSTO
79 63 47 43 31 PTA5 IRQ TPM1CLK RESET
80 64 48 44 32 PTA4 ACMP1O BKGD MS
Table 2-1. Pin Assignment by Package and Pin Sharing Priority (continued)
Pin Number <-- Lowest Priority --> Highest
80 64 48 44 32 Port Pin Alt 1 Alt 2 Alt 3 Alt 4
