Chapter 2 Pins and Connections
MC9S08QE128 MCU Series Reference Manual, Rev. 2
38 Freescale Semiconductor
1
IIC1 pins (SCL1 and SDA1) can be repositioned using IIC1PS in SOPT2. Default locations are
PTA3 and PTA, respectively.
2
SPI1 pins (SS1, MISO1, MOSI1, and SPSCK1) can be repositioned using SPI1PS in SOPT2.
Default locations are PTB5, PTB4, PTB3, and PTB2.
3
If ADC and ACMP1 are enabled, both modules will have access to the pin.
