Chapter 4 Memory
MC9S08QE128 MCU Series Reference Manual, Rev. 2
56 Freescale Semiconductor
Table 4-2. Direct-Page Register Summary (Sheet 1 of 4)
Address
Register
Name
Bit 7 654321Bit 0
0x0000 PTAD PTAD7 PTAD6 PTAD5 PTAD4 PTAD3 PTAD2 PTAD1 PTAD0
0x0001 PTADD PTADD7 PTADD6 PTADD5 PTADD4 PTADD3 PTADD2 PTADD1 PTADD0
0x0002 PTBD PTBD7 PTBD6 PTBD5 PTBD4 PTBD3 PTBD2 PTBD1 PTBD0
0x0003 PTBDD PTBDD7 PTBDD6 PTBDD5 PTBDD4 PTBDD3 PTBDD2 PTBDD1 PTBDD0
0x0004 PTCD PTCD7 PTCD6 PTCD5 PTCD4 PTCD3 PTCD2 PTCD1 PTCD0
0x0005 PTCDD PTCDD7 PTCDD6 PTCDD5 PTCDD4 PTCDD3 PTCDD2 PTCDD1 PTCDD0
0x0006 PTDD PTDD7 PTDD6 PTDD5 PTDD4 PTDD3 PTDD2 PTDD1 PTDD0
0x0007 PTDDD PTDDD7 PTDDD6 PTDDD5 PTDDD4 PTDDD3 PTDDD2 PTDDD1 PTDDD0
0x0008 PTED PTED7 PTED6 PTED5 PTED4 PTED3 PTED2 PTED1 PTED0
0x0009 PTEDD PTEDD7 PTEDD6 PTEDD5 PTEDD4 PTEDD3 PTEDD2 PTEDD1 PTEDD0
0x000A PTFD PTFD7 PTFD6 PTFD5 PTFD4 PTFD3 PTFD2 PTFD1 PTFD0
0x000B PTFDD PTFDD7 PTFDD6 PTFDD5 PTFDD4 PTFDD3 PTFDD2 PTFDD1 PTFDD0
0x000C KBI1SC
0 0 0 0 KBF KBACK KBIE KBIMOD
0x000D KBI1PE KBIPE7 KBIPE6 KBIPE5 KBIPE4 KBIPE3 KBIPE2 KBIPE1 KBIPE0
0x000E KBI1ES KBEDG7 KBEDG6 KBEDG5 KBEDG4 KBEDG3 KBEDG2 KBEDG1 KBEDG0
0x000F IRQSC
0 IRQPDD IRQEDG IRQPE IRQF IRQACK IRQIE IRQMOD
0x0010 ADCSC1 COCO AIEN ADCO ADCH
0x0011 ADCSC2 ADACT ADTRG ACFE ACFGT
— — Reserved Reserved
0x0012 ADCRH
0 0 0 0 ADR11 ADR10 ADR9 ADR8
0x0013 ADCRL ADR7 ADR6 ADR5 ADR4 ADR3 ADR2 ADR1 ADR0
0x0014 ADCCVH
0 0 0 0 ADCV11 ADCV10 ADCV9 ADCV8
0x0015 ADCCVL ADCV7 ADCV6 ADCV5 ADCV4 ADCV3 ADCV2 ADCV1 ADCV0
0x0016 ADCCFG ADLPC ADIV ADLSMP MODE ADICLK
0x0017 APCTL1 ADPC7 ADPC6 ADPC5 ADPC4 ADPC3 ADPC2 ADPC1 ADPC0
0x0018 APCTL2 ADPC15 ADPC14 ADPC13 ADPC12 ADPC11 ADPC10 ADPC9 ADPC8
0x0019 APCTL3 ADPC23 ADPC22 ADPC21 ADPC20 ADPC19 ADPC18 ADPC17 ADPC16
0x001A ACMP1SC ACME ACBGS ACF ACIE ACO ACOPE ACMOD
0x001B ACMP2SC ACME ACBGS ACF ACIE ACO ACOPE ACMOD
0x001C PTGD PTGD7 PTGD6 PTGD5 PTGD4 PTGD3 PTGD2 PTGD1 PTGD0
0x001D PTGDD PTGDD7 PTGDD6 PTGDD5 PTGDD4 PTGDD3 PTGDD2 PTGDD1 PTGDD0
0x001E PTHD PTHD7 PTHD6 PTHD5 PTHD4 PTHD3 PTHD2 PTHD1 PTHD0
0x001F PTHDD PTHDD7 PTHDD6 PTHDD5 PTHDD4 PTHDD3 PTHDD2 PTHDD1 PTHDD0
0x0020 SCI1BDH LBKDIE RXEDGIE
0 SBR12 SBR11 SBR10 SBR9 SBR8
0x0021 SCI1BDL SBR7 SBR6 SBR5 SBR4 SBR3 SBR2 SBR1 SBR0
0x0022 SCI1C1 LOOPS SCISWAI RSRC M WAKE ILT PE PT
0x0023 SCI1C2 TIE TCIE RIE ILIE TE RE RWU SBK
0x0024 SCI1S1 TDRE TC RDRF IDLE OR NF FE PF
0x0025 SCI1S2 LBKDIF RXEDGIF
0 RXINV RWUID BRK13 LBKDE RAF
0x0026 SCI1C3 R8 T8 TXDIR TXINV ORIE NEIE FEIE PEIE
0x0027 SCI1D Bit 7 654321Bit 0
0x0028 SPI1C1 SPIE SPE SPTIE MSTR CPOL CPHA SSOE LSBFE
0x0029 SPI1C2
0 0 0 MODFEN BIDIROE 0 SPISWAI SPC0
