ROHS MC9S08QE128 - Page 57

Chapter 4 Memory
MC9S08QE128 MCU Series Reference Manual, Rev. 2
Freescale Semiconductor 57
0x002A SPI1BR
0 SPPR2 SPPR1 SPPR0 0 SPR2 SPR1 SPR0
0x002B SPI1S SPRF
0 SPTEF MODF 0 0 0 0
0x002C Reserved
0 0 0 0 0 0 0 0
0x002D SPI1D Bit 7 654321Bit 0
0x002E PTJD PTJD7 PTJD6 PTJD5 PTJD4 PTJD3 PTJD2 PTJD1 PTJD0
0x002F PTJDD PTJDD7 PTJDD6 PTJDD5 PTJDD4 PTJDD3 PTJDD2 PTJDD1 PTJDD0
0x0030 IIC1A AD7 AD6 AD5 AD4 AD3 AD2 AD1
0
0x0031 IIC1F MULT ICR
0x0032 IIC1C1 IICEN IICIE MST TX TXAK RSTA
0 0
0x0033 IIC1S TCF IAAS BUSY ARBL
0 SRW IICIF RXAK
0x0034 IIC1D DATA
0x0035 IIC1C2 GCAEN ADEXT 0 0 0 AD10 AD9 AD8
0x0036 Reserved
— — — — — — — —
0x0037 Reserved
— — — — — — — —
0x0038 ICSC1 CLKS RDIV IREFS IRCLKEN IREFSTEN
0x0039 ICSC2 BDIV RANGE HGO LP EREFS ERCLKEN EREFSTEN
0x003A ICSTRM TRIM
0x003B ICSSC DRS/DRST DMX32 IREFST CLKST OSCINIT FTRIM
0x003C KBI2SC
0 0 0 0 KBF KBACK KBIE KBIMOD
0x003D KBI2PE KBIPE7 KBIPE6 KBIPE5 KBIPE4 KBIPE3 KBIPE2 KBIPE1 KBIPE0
0x003E KBI2ES KBEDG7 KBEDG6 KBEDG5 KBEDG4 KBEDG3 KBEDG2 KBEDG1 KBEDG0
0x003F Reserved
— — — — — — — —
0x0040 TPM1SC TOF TOIE CPWMS CLKSB CLKSA PS2 PS1 PS0
0x0041 TPM1CNTH Bit 15 14 13 12 11 10 9 Bit 8
0x0042 TPM1CNTL Bit 7 654321Bit 0
0x0043 TPM1MODH Bit 15 14 13 12 11 10 9 Bit 8
0x0044 TPM1MODL Bit 7 654321Bit 0
0x0045 TPM1C0SC CH0F CH0IE MS0B MS0A ELS0B ELS0A
0 0
0x0046 TPM1C0VH Bit 15 14 13 12 11 10 9 Bit 8
0x0047 TPM1C0VL Bit 7 654321Bit 0
0x0048 TPM1C1SC CH1F CH1IE MS1B MS1A ELS1B ELS1A
0 0
0x0049 TPM1C1VH Bit 15 14 13 12 11 10 9 Bit 8
0x004A TPM1C1VL Bit 7 654321Bit 0
0x004B TPM1C2SC CH2F CH2IE MS2B MS2A ELS2B ELS2A
0 0
0x004C TPM1C2VH Bit 15 14 13 12 11 10 9 Bit 8
0x004D TPM1C2VL Bit 7 654321Bit 0
0x004E-
0x004F
Reserved
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
0x0050 TPM2SC TOF TOIE CPWMS CLKSB CLKSA PS2 PS1 PS0
0x0051 TPM2CNTH Bit 15 14 13 12 11 10 9 Bit 8
0x0052 TPM2CNTL Bit 7 654321Bit 0
0x0053 TPM2MODH Bit 15 14 13 12 11 10 9 Bit 8
Table 4-2. Direct-Page Register Summary (Sheet 2 of 4)
Address
Register
Name
Bit 7 654321Bit 0
