Chapter 4 Memory
MC9S08QE128 MCU Series Reference Manual, Rev. 2
58 Freescale Semiconductor
0x0054 TPM2MODL Bit 7 654321Bit 0
0x0055 TPM2C0SC CH0F CH0IE MS0B MS0A ELS0B ELS0A
0 0
0x0056 TPM2C0VH Bit 15 14 13 12 11 10 9 Bit 8
0x0057 TPM2C0VL Bit 7 654321Bit 0
0x0058 TPM2C1SC CH1F CH1IE MS1B MS1A ELS1B ELS1A
0 0
0x0059 TPM2C1VH Bit 15 14 13 12 11 10 9 Bit 8
0x005A TPM2C1VL Bit 7 654321Bit 0
0x005B TPM2C2SC CH2F CH2IE MS2B MS2A ELS2B ELS2A
0 0
0x005C TPM2C2VH Bit 15 14 13 12 11 10 9 Bit 8
0x005D TPM2C2VL Bit 7 654321Bit 0
0x005E-
0x005F
Reserved
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
0x0060 TPM3SC TOF TOIE CPWMS CLKSB CLKSA PS2 PS1 PS0
0x0061 TPM3CNTH Bit 15 14 13 12 11 10 9 Bit 8
0x0062 TPM3CNTL Bit 7 654321Bit 0
0x0063 TPM3MODH Bit 15 14 13 12 11 10 9 Bit 8
0x0064 TPM3MODL Bit 7 654321Bit 0
0x0065 TPM3C0SC CH0F CH0IE MS0B MS0A ELS0B ELS0A
0 0
0x0066 TPM3C0VH Bit 15 14 13 12 11 10 9 Bit 8
0x0067 TPM3C0VL Bit 7 654321Bit 0
0x0068 TPM3C1SC CH1F CH1IE MS1B MS1A ELS1B ELS1A
0 0
0x0069 TPM3C1VH Bit 15 14 13 12 11 10 9 Bit 8
0x006A TPM3C1VL Bit 7 654321Bit 0
0x006B TPM3C2SC CH2F CH2IE MS2B MS2A ELS2B ELS2A
0 0
0x006C TPM3C2VH Bit 15 14 13 12 11 10 9 Bit 8
0x006D TPM3C2VL Bit 7 654321Bit 0
0x006E TPM3C3SC CH3F CH3IE MS3B MS3A ELS3B ELS3A
0 0
0x006F TPM3C3VH Bit 15 14 13 12 11 10 9 Bit 8
0x0070 TPM3C3VL Bit 7 654321Bit 0
0x0071 TPM3C4SC CH4F CH4IE MS4B MS4A ELS4B ELS4A
0 0
0x0072 TPM3C4VH Bit 15 14 13 12 11 10 9 Bit 8
0x0073 TPM3C4VL Bit 7 654321Bit 0
0x0074 TPM3C5SC CH5F CH5IE MS5B MS5A ELS5B ELS5A
0 0
0x0075 TPM3C5VH Bit 15 14 13 12 11 10 9 Bit 8
0x0076 TPM3C5VL Bit 7 654321Bit 0
0x0077 Reserved
— — — — — — — —
0x0078 PPAGE
0 0 0 0 0 XA16 XA15 XA14
0x0079 LAP2
0 0 0 0 0 0 0 LA16
Table 4-2. Direct-Page Register Summary (Sheet 3 of 4)
Address
Register
Name
Bit 7 654321Bit 0
