3 Product Overview
xMate ER7Hardware Installation Manual 13
Figure 5. Symbols and labels
Position Label type Remarks
1 Arm body logo
2 Product nameplate Indicates product model and other
product information.
3 Electrical hazard
symbol
Do not touch the electrical
components inside a live robot to
avoid the risk of electric shock.
