6 Electrical Connections
202208081959/V0.1
38 xMate ER7Hardware Installation Manual
(self-locking)
OFF Off Not powered on
ON Steady red Powered on
6.3.2 Power input
The input power interface of the power adapter is an IEC C14 socket (pin-type), which
adapts to IEC C13 plugs (hole-type). The rated current of the external mains fuse is 10 A.
The input power indications are as follows.
Rotary switch
(self-locking)
Indicator
status
Adapter
status
OFF Off Not powered
on
ON Steady red Powered on
The electrical specifications of the input power are listed below.
ROKAE power adapter
Output
DC voltage 48 V
Rated current 21 A
Ripple and noise 150 mVp-p
Input
Voltage range 90 to 264 VAC
Frequency range 47 to 63Hz
Efficiency 90%
Environment
Operating
temperature
-20 to +60°C
Operating humidity 20 to 90% RH, non-condensing
Storage
temperature and
humidity
-40 to +85°C, 10 to 95% RH
Vibration resistance 10 to 500 Hz, 2G 10 min/cycle, 60 min
for each of the X, Y, and Z axes
