65
Editing the system settings
43 43 W SaturatorW Saturator
This is a variety of saturator, and is distinctive for its warmer sound.
Balance W
Balance D
Balance D
L in L out
R outR in
Parameter Value Explanation
Drive 0.0–+48.0 [dB] Strength of distortion
Drive Balance
D100: 0W–D0:
100W
Volume balance between the dry sound
(D) and effect sound (W)
44 44 Gt Amp Sim Gt Amp Sim (Guitar Amp Simulator)(Guitar Amp Simulator)
This is an eect that simulates the sound of a guitar amplier.
L in
R in
L out
R out
Pan L
Pan R
SpeakerPre Amp
Parameter Value Explanation
Level 0–127 Output Level
Pre Amp Drive 0–127
Volume and amount of distortion of
the amp
45 45 EP Amp Sim EP Amp Sim (RD EP Amp Simulator)(RD EP Amp Simulator)
This is an eect that was developed for the RD series SuperNatural
E.Piano.
L out
R out
L in
R in
Parameter Value Explanation
Tremolo Depth 0–127 Depth of the tremolo effect
Tremolo Speed
(Hz)
0.05–10.00 [Hz] Rate of the tremolo effect
46 46 Speaker SimSpeaker Sim
Simulates the speaker type and mic settings used to record the
speaker sound.
L in L out
R outR in
Speaker
Speaker
Parameter Value Explanation
Mic Level 0–127 Volume of the microphone
Direct Level 0–127 Volume of the direct sound
47 47 CompressorCompressor
Flattens out high levels and boosts low levels, smoothing out
uctuations in volume.
L in L out
R outR in
Compressor 2-Band EQ
Compressor 2-Band EQ
Parameter Value Explanation
Threshold -60–0 [dB]
Adjusts the volume at which
compression begins
Attack 0–124
Sets the speed at which compression
starts
48 48 M/S Comp M/S Comp (Mid-Side Compressor)(Mid-Side Compressor)
This eect allows the left/right signals that have similar phase to be
adjusted to a dierent sense of volume than the left/right signals that
have dierent phase.
L in L out
R outR in
Side
Mid
LR
MS
MS
LR
Parameter Value Explanation
S Threshold -60–0 [dB]
Adjusts the volume at which
compression begins
M Threshold -60–0 [dB]
Adjusts the volume at which
compression begins
