163
Effect/Parameter List
35: OVERDRIVE
Creates a soft distortion similar to that produced by vacuum
tube amplifiers.
36: DISTORTION
Produces a more intense distortion than Overdrive. The
parameters are the same as for “35: OVERDRIVE.”
37: VS OVRDRIVE (VS OVERDRIVE)
This is an overdrive that provides heavy distortion.
38: VS DIST(VS DISTORTION)
This is a distortion effect that provides heavy distortion. The
parameters are the same as for “37: VS OVERDRIVE.”
39: GTR AMP SIM
(GUITAR AMP SIMULATOR)
This is an effect that simulates the sound of a guitar amplifier.
Specifications of each Speaker Type
The speaker column indicates the diameter of each speaker
unit (in inches) and the number of units.
Assignable Parameters
MFX Control
Level, Amp Type, Drive, Pan
Parameter
Value Description
Drive 0–127
Degree of distortion
Also changes the volume.
Amp Type
SMALL,
BUILT-IN,
2-STACK,
3-STACK
Type of guitar amp
SMALL
: small amp
BUILT-IN
: single-unit type amp
2-STACK
: large double stack amp
3-STACK
: large triple stack amp
Low Gain -15– +15 dB Gain of the low range
High Gain -15– +15 dB Gain of the high range
Pan L64–63R Stereo location of the output sound
Level 0–127 Output Level
Assignable Parameters
MFX Control
Level, Tone, Amp Type, Drive, Pan
Parameter
Value Description
Drive
0–127
Degree of distortion
Also changes the volume.
Tone 0–127 Sound quality of the Overdrive effect
Amp Sw OFF, ON Turns the Amp Simulator on/off.
Amp Type
SMALL,
BUILT-IN,
2-STACK,
3-STACK
Type of guitar amp
SMALL
: small amp
BUILT-IN
: single-unit type amp
2-STACK
: large double stack amp
3-STACK
: large triple stack amp
Low Gain -15– +15 dB Gain of the low range
High Gain -15– +15 dB Gain of the high range
Pan L64–63R Stereo location of the output sound
Level 0–127 Output Level
Assignable Parameters
MFX Control
Pre Amp Master, Pre Amp Volume, Pre Amp, Speaker
Parameter Value Description
Pre Amp Sw
OFF, ON Turns the amp switch on/off.
Pre Amp
JC-120,
CLEAN TWIN,
MATCH DRIVE,
BG LEAD,
MS1959I,
MS1959II,
MS1959I+II,
SLDN LEAD,
METAL5150,
METAL LEAD,
OD-1,
OD-2 TURBO,
DISTORTION,
FUZZ
Type of guitar amp
Pre Amp Volume 0–127
Volume and amount of distortion of the
amp
Pre Amp Master
0–127 Volume of the entire pre-amp
Pre Amp Gain
LOW,
MIDDLE,
HIGH
Amount of pre-amp distortion
Pre Amp Bass
0–127
Tone of the bass/mid/treble
frequency range
Middle cannot be set if “Match Drive”
is selected as the Pre Amp Type.
Pre Amp Middle
Pre Amp Treble
Pre Amp
Presence
0–127
Tone for the ultra-high frequency
range
Pre Amp Bright OFF, ON
Turning this “On” produces a sharper
and brighter sound.
This parameter applies to the “JC-
120,” “Clean Twin,” and “BG Lead”
Pre Amp Types.
Speaker Sw OFF, ON
Determines whether the signal passes
through the speaker (ON), or not
(OFF).
Speaker
(See the table
below.)
Type of speaker
Mic Setting 1, 2, 3
Adjusts the location of the mic that’s
capturing the sound of the speaker.
This can be adjusted in three steps,
from 1 to 3, with the mic becoming
more distant as the value increases.
Mic Level 0–127 Volume of the microphone
Direct Level 0–127 Volume of the direct sound
Pan L64–63R Stereo location of the output
Level 0–127 Output level
Type
Cabinet Speaker Microphone
SMALL 1 small open-back enclosure 10 dynamic
SMALL 2 small open-back enclosure 10 dynamic
MIDDLE open back enclosure 12 x 1 dynamic
JC-120 open back enclosure 12 x 2 dynamic
BUILT-IN 1 open back enclosure 12 x 2 dynamic
BUILT-IN 2 open back enclosure 12 x 2 condenser
BUILT-IN 3 open back enclosure 12 x 2 condenser
BUILT-IN 4 open back enclosure 12 x 2 condenser
BUILT-IN 5 open back enclosure 12 x 2 condenser
BG STACK 1 sealed enclosure 12 x 2 condenser
BG STACK 2 large sealed enclosure 12 x 2 condenser
MS STACK 1 large sealed enclosure 12 x 4 condenser
MS STACK 2 large sealed enclosure 12 x 4 condenser
METAL STACK large double stack 12 x 4 condenser
2-STACK large double stack 12 x 4 condenser
3-STACK large triple stack 12 x 4 condenser
Parameter
Value Description
