173
Effect/Parameter List
77: CHO
→
FLANGER
(CHORUS
→
FLANGER)
This effect connects a chorus and a flanger in series.
78: SYM.RESONCE
(SYMPATHETIC RESONANCE)
On an acoustic piano, holding down the damper pedal allows
other strings to resonate in sympathy with the notes you play,
creating rich and spacious resonances. This effect simulates
these sympathetic resonances.
* This effect is used only for MFX1.
Flngr Mode
Hz, note
When this is set to “note,” the effect is
synchronized with the tempo.
Fln Rate(Hz) 0.05–10.00 Hz Frequency of modulation (Hz)
Fln Rate( ) note (*1) Frequency of modulation (note)
Flngr Depth 0–127 Depth of modulation
Flngr Feedback -98– +98%
Adjusts the proportion of the flanger
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
Flngr Bal
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the flanger sound (W)
Delay Mode ms, note
When this is set to “note,” the effect is
synchronized with the tempo.
Delay (ms) 1–2600 ms
Adjusts the delay time from the direct
sound until the delay sound is heard.
(Hz)
Delay ( ) note (*1)
Adjusts the delay time from the direct
sound until the delay sound is heard.
(note)
Delay Feedback -98– +98%
Adjusts the proportion of the delay
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
Delay HF Damp
200–8000 Hz,
BYPASS
Adjusts the frequency above which
sound fed back to the effect will be
cut. If you do not want to cut the high
frequencies, set this parameter to
BYPASS.
Delay Bal
D100:0W–
D0:100W
Adjusts the volume balance between
the sound that is sent through the delay
(W) and the sound that is not sent
through the delay (D).
Level 0–127 Output Level
Assignable Parameters
MFX Control
Chorus Bal, Flngr Bal, Chorus Depth, Cho Rate, Fln Rate,
Flngr Feedback
Parameter
Value Description
Chorus PreDly
0.0–100.0 ms
Adjusts the delay time from the direct
sound until the chorus sound is heard.
Rate Mode Hz, note
When this is set to “note,” the effect is
synchronized with the tempo.
Cho Rate(Hz) 0.05–10.00 Hz
Modulation frequency of the chorus
effect (Hz)
Cho Rate ( ) note (*1)
Modulation frequency of the chorus
effect (note)
Chorus Depth 0–127 Modulation depth of the chorus effect
Chorus Bal
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the chorus sound (W)
Flngr PreDly 0.0–100.0 ms
Adjusts the delay time from when the
direct sound begins until the flanger
sound is heard.
Flngr Mode Hz, note
When this is set to “note,” the effect is
synchronized with the tempo.
Fln Rate(Hz) 0.05-10.00 Hz
Modulation frequency of the flanger
effect (Hz)
Fln Rate( ) note (*1)
Modulation frequency of the flanger
effect (note)
Flngr Depth 0-127 Modulation depth of the flanger effect
Flngr Feedback -98– +98%
Adjusts the proportion of the flanger
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
Parameter
Value Description
Flngr Bal
D100:0W–
D0:100W
Adjusts the volume balance between
the sound that is sent through the
flanger (W) and the sound that is not
sent through the flanger (D).
Level 0–127 Output Level
Assignable Parameters
MFX Control
Depth, Damper, P-Sft Amount, P-Sft Level
Parameter
Value Description
Depth
0–127 Depth of the effect
Damper 0–127
Depth to which the damper pedal is
pressed (controls the resonant sound)
Pre LPF
16–15000 Hz,
BYPASS
Frequency of the filter that cuts the
high-frequency content of the input
sound (BYPASS: no cut)
Pre HPF
BYPASS, 16–
15000 Hz
Frequency of the filter that cuts the low-
frequency content of the input sound
(BYPASS: no cut)
Peaking Freq 200–8000 Hz
Frequency of the filter that boosts/cuts
a specific frequency region of the
input sound
Peaking Gain -15– +15 dB
Amount of boost/cut produced by the
filter at the specified frequency region
of the input sound
Peaking Q
0.5, 1.0, 2.0,
4.0, 8.0
Width of the frequency region
boosted/cut by the `Peaking Gain’
parameter (larger values make the
region narrower)
HF Damp
16–15000 Hz,
BYPASS
Frequency at which the high-frequency
content of the resonant sound will be
cut (BYPASS: no cut)
LF Damp Freq
BYPASS,
16–15000 Hz
Frequency at which the low-frequency
content of the resonant sound will be
cut (BYPASS: no cut)
Lid 1–7
Adjusts the extent to which the lid of
the grand piano is open.
Level 0–127 Output Level
P-Sft Amount 0–127 Amount of resonance
P-Sft Level 0–127
Volume level of the resonant
component
P-Sft LPF
16–15000 Hz,
BYPASS
Basic frequency at which the filter cuts
the high-frequency portion of the
resonant component (BYPASS: no cut)
P-Sft HPF
BYPASS,
16–15000 Hz
Basic frequency at which the filter cuts
the low-frequency portion of the
resonant component (BYPASS: no cut)
P-Sft to Rev 0–127
Volume of additional resonance
added to resonant component
Damper offset 0–64
Volume of additional slight resonance
when the damper pedal is not pressed
Parameter
Value Description
RD-700GX_e.book 173 ページ ２００８年２月１３日 水曜日 午後５時４９分
